Brief of Product
Centrifugal Process Pumps
AERON Pumps is manufacturer of Industrial Pumps with the different categories. We manufactured very wide range of pump with different model and capacity.
Centrifugal Process Pumps : in that case we have so many model with different capacity.
We facilitate our clients with Centrifugal Chemical Process Pumps, which are single stage end suction centrifugal pumps used in fertilizer plants and effluent water treatment plants. These chemical process pumps are robust, require less maintenance and manufactured as per DIN 34256 and ISO 2858 standards. Acclaimed for precise engineering, these can be customized to suit client's specifications.
Centrifugal Chemical Process Pumps are available in following capacities and dimensions:
- Horizontal
- Foot mounted
- Single stage
- End suction and Top Center-line Discharge
Application Areas:
- Chemical process industries
- Sugar plants
- Organic & inorganic liquids refineries
- Cooling towers
- Heating and air conditioning plants
- Dyes & intermediates oil extraction and waste oil refineries
- Bulk drugs and pharmaceutical
- Fire fighting
- Water supply hydrocarbon
- Volatile liquids
- Pulp and paper textile
- Power steel
- Cement agriculture fiber
- Jet dying
- Thermic fluid
- Hot water
Application:
- Hot and cold water circulation cooling water circulation
- Drip irrigation water supply and building services
- Thermic fluid, jet dyeing, volatile fluids, heat exchanger
- Condensate handling, fire fighting system, environmental engineering, marine refrigeration and cooling tower installation etc
- Chemicals petrochemicals pharmaceuticals, refineries, steel plant, sugar, paper, laminates industries, textiles, rubber, handling of hydrocarbons, organic and inorganic chemicals, D.M water, food industries, salt plants, power plants and in industries such as pulp ,fertilizers and other process industries etc
Salient features
-
High quality Aluminum extruded body
-
Compact monobloc construction
-
Easy to install
-
Satisfactory performance at wide voltage range
-
Wide range of operating heads with maximum efficiency.
-
Very smooth and silent operation.
Model |
KW (HP) |
PH |
Suc (MM) |
Dis (MM) |
Dis in LPM at Various Total Head in Mtrs |
Shut off Head |
|||||||
Head |
3 |
6 |
9 |
12 |
15 |
18 |
20 |
||||||
0511 |
0.37(0.5) |
1 |
25 |
25 |
Dis |
145 |
135 |
115 |
75 |
25 |
0 |
0 |
16M |
0531 |
0.37(0.5) |
3 |
|||||||||||
111 |
0.75 (1.0) |
1 |
25 |
25 |
Dis |
160 |
150 |
140 |
135 |
125 |
115 |
75 |
21M |
131 |
0.75 (1.0) |
3 |
Pump Casing and Impeller |
Die Pressed From SS 316 Material |
Impeller and Backplate |
SS 316 Investment Casting |
Mechanical Seal |
TC v/s TC with Polymer VITON STEEL Parts in 316 |
TEFC Motor |
1PH 230V 50Hz or 3PH 415V 50 Hz |
